DN | ØA | 公头订货号 | 母头订货号 | |
06 | ¼” BSP | 101.11111AB | 101.12111AB | 350Bar |
¼” NPTF | 101.11111BB | 101.12111BB | ||
⅜” BSP | 101.11112AC | 101.12112AC | ||
10 | ⅜” NPTF | 101.11112BC | 101.12112BC | 300Bar |
⅜” BSPT | 101.11112DC | 101.12112DC | ||
9/16” 18ORB | 101.11112GC | 101.12112GC | ||
½” BSP | 101.11113AD | 101.12113AD | ||
13 | ½” NPTF | 101.11113BD | 101.12113BD | 300Bar |
M22x1,5 | 101.11113NG | 101.12113NG | ||
¾” - 16ORB | 101.11113GF | 101.12113GF | ||
⅞” 14ORB | 101.11113GH | 101.12113GH | ||
¾” BSP | 101.11114AE | 101.12114AE | ||
20 | ¾” NPTF | 101.11114BE | 101.12114BE | 250Bar |
1 1/16”- | 101.11114GK | 101.12114GK | ||
12ORB | ||||
1” BSP | 101.11115AF | 101.12115AF | ||
25 | 1” NPTF | 101.11115BF | 101.12115BF | 230Bar |
1 5/16”- | 101.11115GO | 101.12115GO | ||
12ORB | ||||
32 | 1 ¼” BSP | 101.11116AG | 101.12116AG | 230Bar |
1 ¼” NPTF | 101.11116BG | 101.12116BG | ||
40 | 1 ½” BSP | 101.11117AH | 101.12117AH | 200Bar |
1 ½” NPTF | 101.11117BH | 101.12117BH | ||
50 | 2” BSP | 101.11118AI | 101.12118AI | 130Bar |
2” NPTF | 101.11118BI | 101.12118BI | ||
DNØA | 材料 | 订货号 | ||
不锈钢316 | 101.21123AD | 200 Bar | ||
13 | ½” BSP | 不锈钢303 | 101.31123AD | |
黄铜 | 101.41123AD 160 Bar | |||
½” BSP M. | 不锈钢316 | 102.21123AO 200Bar | ||
DN | ØA | 材料 | 订货号 | ||
13 | ½” BSP | 不锈钢316 | 101.22123AD | 200 | Bar |
不锈钢 303 | 101.32123AD | ||||
黄铜 | 101.42123AD 160 | Bar | |||
防尘盖 防尘帽
DN | 红色 | 蓝色 | 黄色 | 绿色 | 黑色 | 白色 |
101.5321AA | 101.5331AA | * | ||||
06 | 101.5311AA | 101.5341AA | 101.5351AA | |||
10 | 101.5312AA | * | * | * | * | * |
13 | 101.5313AA | 101.5323AA | 101.5333AA | 101.5343AA | 101.5353AA | 101.5363AA |
20 | 101.5314AA | 101.5324AA | 101.5334AA | 101.5344AA | 101.5354AA | * |
25 | 101.5315AA | * | * | * | * | * |
DN | 红色 | 蓝色 | 黄色 | 绿色 | 黑色 | 白色 |
101.5421AA | 101.5431AA | * | ||||
06 | 101.5411AA | 101.4341AA | 101.5451AA | |||
10 | 101.5412AA | * | * | * | * | * |
13 | 101.5413AA | 101.5423AA | 101.5433AA | 101.5443AA | 101.5453AA | 101.5463AA |
20 | 101.5414AA | 101.5424AA | 101.5434AA | 101.5444AA | 101.5454AA | * |
25 | 101.5415AA | * | * | * | * | * |
DN | ØA | ØT | 订货号 | ||
06 | M12x1,5 | 6L | 102.11111JB | 350Bar | |
M14x1,5 | 8L | 102.11111JC | |||
10 | ⅜” BSP M. | * | 102.11112AN | 300Bar | |
M14x1,5 | 8L | 102.11112JC | |||
M16x1,5 | 10L | 102.11112JD | |||
M14x1,5 | 8L | 102.11113JC | |||
13 | M16x1,5 | 10L | 102.11113JD | 300Bar | |
M18x1,5 | 12L | 102.11113JE | |||
M22x1,5 | 15L | 102.11113JG | |||
M26x1,5 | 18L | 102.11113JI | |||
M18x1,5 | 12L | 102.11114JE | |||
20 | M22x1,5 | 15L | 102.11114JG | 250Bar | |
M26x1,5 | 18L | 102.11114JI | |||
M30x2 | 22L | 102.11114JJ | |||
M26x1,5 | 18L | 102.11115JI | |||
25 | M30x2 | 22L | 102.11115JJ | 230Bar | |
M36x2 | 28L | 102.11115JK | |||
M45x2 | 35L | 102.11115JM | |||
10 | M16x1,5 | 8S | 102.11112KN | 300Bar | |
M18x1,5 | 10S | 102.11112KC | |||
M20x1,5 | 12S | 102.11112KD | |||
M18x1,5 | 10S | 102.11113KC | |||
13 | M20x1,5 | 12S | 102.11113KD | 300Bar | |
M22x1,5 | 14S | 102.11113KE | |||
M24x1,5 | 16S | 102.11113KG | |||
20 | M24x1,5 | 16S | 102.11114KI | 250Bar | |
M30x2 | 20S | 102.11114KJ | |||
M30x2 | 20S | 102.11115KI | |||
25 | M36x2 | 25S | 102.11115KJ | 230Bar | |
M42x2 | 30S | 102.11115KK | |||
M52x2 | 38S | 102.11115KM |
DN | ØA | ØT | 订货号 | ||
06 | M12x1,5 | 6L | 102.12111JB | 350Bar | |
M14x1,5 | 8L | 102.12111JC | |||
10 | ⅜” BSP M. | * | 102.12112AN | 300Bar | |
M14x1,5 | 8L | 102.12112JC | |||
M16x1,5 | 10L | 102.12112JD | |||
M14x1,5 | 8L | 102.12113JC | |||
13 | M16x1,5 | 10L | 102.12113JD | 300Bar | |
M18x1,5 | 12L | 102.12113JE | |||
M22x1,5 | 15L | 102.12113JG | |||
M26x1,5 | 18L | 102.12113JI | |||
M18x1,5 | 12L | 102.12114JE | |||
20 | M22x1,5 | 15L | 102.12114JG | 250Bar | |
M26x1,5 | 18L | 102.12114JI | |||
M30x2 | 22L | 102.12114JJ | |||
M26x1,5 | 18L | 102.12115JI | |||
25 | M30x2 | 22L | 102.12115JJ | 230Bar | |
M36x2 | 28L | 102.12115JK | |||
M45x2 | 35L | 102.12115JM | |||
10 | M16x1,5 | 8S | 102.12112KN | 300Bar | |
M18x1,5 | 10S | 102.12112KC | |||
M20x1,5 | 12S | 102.12112KD | |||
M18x1,5 | 10S | 102.12113KC | |||
13 | M20x1,5 | 12S | 102.12113KD | 300Bar | |
M22x1,5 | 14S | 102.12113KE | |||
M24x1,5 | 16S | 102.12113KG | |||
20 | M24x1,5 | 16S | 102.12114KI | 250Bar | |
M30x2 | 20S | 102.12114KJ | |||
M30x2 | 20S | 102.12115KI | |||
25 | M36x2 | 25S | 102.12115KJ | 230Bar | |
M42x2 | 30S | 102.12115KK | |||
M52x2 | 38S | 102.12115KM |
DN | ØA | ØT | 订货号 | |
06 | M12x1,5 | 6L | 102.11111LB | 350Bar |
M14x1,5 | 8L | 102.11111LC | ||
10 | M14x1,5 | 8L | 102.11112LC | 300Bar |
M16x1,5 | 10L | 102.11112LD | ||
M16x1,5 | 8S | 102.11112MD | ||
M14x1,5 | 8L | 102.11113LC | ||
13 | M16x1,5 | 10L | 102.11113LD | 300Bar |
M18x1,,5 | 12L | 102.11113LE | ||
M22x1,5 | 15L | 102.11113LG | ||
M26x1,5 | 18L | 102.11113LI | ||
M18x1,5 | 12l | 102.11114LE | ||
20 | M22x1,5 | 15L | 102.11114LG | 250Bar |
M26x1,5 | 18L | 102.11114LI | ||
M30x2 | 22L | 102.11114LJ | ||
25 | M30x2 | 22L | 102.11115LJ | 230Bar |
M36x2 | 28L | 102.11115LK | ||
M45x2 | 35L | 102.11115LM |
10 | M16x1,5 | 8S | 102.11112MD | 300Bar |
M18x1,5 | 10S | 102.11112ME | ||
M20x1,5 | 12S | 102.11112MF | ||
M18x1,5 | 10S | 102.11113ME | ||
13 | M20x1,5 | 12S | 102.11113MF | 300Bar |
M22x1,5 | 14S | 102.11113MG | ||
M24x1,5 | 16S | 102.11113MH | ||
20 | M24x1,5 | 16S | 102.11114MH | 250Bar |
M30x2 | 20S | 102.11114MJ | ||
M30x2 | 20S | 102.11115MJ | ||
25 | M36x2 | 25S | 102.11115MK | 230Bar |
M42x2 | 30S | 102.11115ML | ||
M52x2 | 38S | 102.11115MN |
DN | ØA | ØT | REF. |
06 | M12x1,5 | 6L | 102.12111LB |
M14x1,5 | 8L | 102.12111LC | |
10 | M14x1,5 | 8L | 102.12112LC |
M16x1,5 | 10L | 102.12112LD | |
M16x1,5 | 8S | 102.12112MD | |
M14x1,5 | 8L | 102.12113LC | |
13 | M16x1,5 | 10L | 102.12113LD |
M18x1,,5 | 12L | 102.12113LE | |
M22x1,5 | 15L | 102.12113LG | |
M26x1,5 | 18L | 102.12113LI | |
M18x1,5 | 12l | 102.12114LE | |
20 | M22x1,5 | 15L | 102.12114LG |
M26x1,5 | 18L | 102.12114LI | |
M30x2 | 22L | 102.12114LJ | |
25 | M30x2 | 22L | 102.12115LJ |
M36x2 | 28L | 102.12115LK | |
M45x2 | 35L | 102.12115LM |
10 | M16x1,5 | 8S | 102.12112MD | 300Bar |
M18x1,5 | 10S | 102.12112ME | ||
M20x1,5 | 12S | 102.12112MF | ||
M18x1,5 | 10S | 102.12113ME | ||
13 | M20x1,5 | 12S | 102.12113MF | 300Bar |
M22x1,5 | 14S | 102.12113MG | ||
M24x1,5 | 16S | 102.12113MH | ||
20 | M24x1,5 | 16S | 102.12114MH | 250Bar |
M30x2 | 20S | 102.12114MJ | ||
M30x2 | 20S | 102.12115MJ | ||
25 | M36x2 | 25S | 102.12115MK | 230Bar |
M42x2 | 30S | 102.12115ML | ||
M52x2 | 38S | 102.12115MN |
DN | ØA | 公头 | 母头 | ||
06 | ¼” BSP | 102.11111AB | 102.12111AB | 350Bar | |
¼” NPTF | 102.11111BB | 102.12111BB | |||
M14x1,5 | 102.11111NC | 102.12111NC | |||
¼” BSP | 102.11112AB | 102.12112AB | |||
10 | ⅜” BSP | 102.11112AC | 102.12112AC | ||
⅜” NPTF | 102.11112BC | 102.12112BC | |||
M16x1,5 | 102.11112ND | 102.12112ND | |||
⅜” BSP | 102.11113AC | 102.12113AC | 300Bar | ||
½” BSP | 102.11113AD | 102.12113AD | |||
½” NPTF | 102.11113BD | 102.12113BD |
M18x1,5 102.11113NE 102.12113NE M22x1,5 102.11113NG 102.12113NG¾” -16ORB 102.11113GF 102.12113GF ⅞” -14ORB 102.11113GH 102.12113GH ¾” BSP 102.11114AE 102.12114AE
¾” NPTF 102.11114BE 102.12114BE 230Bar M22x1,5 102.11114NG 102.12114NG
¾” BSP | 102.11115AE | 102.12115AE | ||
25 | 1” BSP | 102.11115AF | 102.12115AF | 230Bar |
1” NPTF | 102.11115BF | 102.12115BF | ||
DN | ØA | 公头 | 母头 | |
⅛” BSP | 103.11110AA | 103.12110AA | ||
04 | 350Bar | |||
⅛” NPTF | 103.11110BA | 103.12110BA | ||
06 | ¼” BSP | 103.11111AB | 103.12111AB | 520Bar |
¼” NPTF | 103.11111BB | 103.12111BB | ||
10 | ⅜” BSP | 103.11112AC | 103.12112AC | 345Bar |
⅜” NPTF | 103.11112BC | 103.12112BC | ||
¾”-16ORB | 103.11112GF | 103.12112GF | ||
½” BSP | 103.11113AD | 103.12113AD | ||
13 | ½” NPTF | 103.11113BD | 103.12113BD | 345Bar |
¾” - 16ORB | 103.11113GF | 103.12113GF | ||
⅞” 14ORB | 103.11113GH | 103.12113GH | ||
¾” BSP | 103.11114AE | 103.12114AE | ||
20 | ¾” NPTF | 103.11114BE | 103.12114BE | 280Bar |
1 1/16”- | 103.11114GK | 103.12114GK | ||
12ORB | ||||
1” BSP | 103.11115AF | 103.12115AF | ||
25 | 1” NPTF | 103.11115BF | 103.12115BF | 280Bar |
1 5/16”- | 103.11115GO | 103.12115GO | ||
12ORB | ||||
DN | ØA | 公头 | 母头 | |
04 | ⅛” BSP | 103.21120AA | 103.22120AA | 280Bar |
⅛” NPTF | 103.21120BA | 103.22120BA | ||
06 | ¼” BSP | 103.21121AB | 103.22121AB | 380Bar |
¼” NPTF | 103.21121BB | 103.22121BB | ||
10 | ⅜” BSP | 103.21122AC | 103.22122AC | |
⅜” NPTF | 103.21122BC | 103.22122BC | 260Bar | |
¾”-16ORB | 订单生产 | |||
½” BSP | 103.21123AD | 103.22123AD | ||
13 | ½” NPTF | 103.21123BD | 103.22123BD | 260Bar |
¾” - 16ORB | 订单生产 | |||
⅞” 14ORB | 订单生产 | |||
¾” BSP | 103.21124AE | 103.22124AE | ||
20 | ¾” NPTF | 103.21124BE | 103.22124BE | 210Bar |
1 1/16”- | 订单生产 | |||
12ORB | ||||
1” BSP | 103.21125AF | 103.22125AF | ||
25 | 1” NPTF | 103.21125BF | 103.22125BF | 210Bar |
DN | ØA | 公头 | 母头 | |
04 | ⅛” BSP | 103.41120AA | 103.42120AA | 90Bar |
⅛” NPTF | 103.41120BA | 103.42120BA | ||
06 | ¼” BSP | 103.41121AB | 103.42121AB | 90Bar |
¼” NPTF | 103.41121BB | 103.42121BB | ||
10 | ⅜” BSP | 103.41122AC | 103.42122AC | 80Bar |
⅜” NPTF | 103.41122BC | 103.42122BC | ||
¾”-16ORB | 订单生产 | |||
½” BSP | 103.41123AD | 103.42123AD | ||
13 | ½” NPTF | 103.41123BD | 103.42123BD | 80Bar |
¾” - 16ORB | 订单生产 | |||
⅞” 14ORB | 订单生产 | |||
¾” BSP | 103.41124AE | 103.42124AE | ||
20 | ¾” NPTF | 103.41124BE | 103.42124BE | 70Bar |
1 1/16”- | 订单生产 | |||
12ORB | ||||
1” BSP | 103.41125AF | 103.42125AF | ||
25 | 1” NPTF | 103.41125BF | 103.42125BF | 70Bar |
防尘盖
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
103.5320AB | * | * | |||||
04 | * | * | * | ||||
06 | 103.5311AA | 103.5321AA | 103.5331AA | 103.5341AA | 103.5351AA | * | |
10 | * | 103.5322AB | * | * | * | * | |
13 | * | 103.5323AA | * | * | * | * | |
20 | * | 103.5324AA | * | * | * | * | |
25 | * | 103.5325AB | * | * | * | * |
防尘帽
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
103.5420AB | * | * | |||||
04 | * | * | * | ||||
06 | 103.5411AA | 103.5421AA | 103.5431AA | 103.5441AA | 103.5451AA | * | |
10 | * | 103.5422AB | * | * | * | * | |
13 | * | 103.5423AA | * | * | * | * | |
20 | * | 103.5424AA | * | * | * | * | |
25 | * | 103.5425AB | * | * | * | * |
标准型号（碳钢）
DN | ØA | 公头 | 母头 | ||
1 ¼” BSP | 103.11117AG | 103.12117AG | |||
40 | 1 ¼” NPTF | 103.11117BG | 103.12117BG | ||
1 ½” BSP | 103.11117AH | 103.12117AH | |||
1 ½” NPTF | 103.11117BH | 103.12117BH | |||
2” BSP | 103.11118AI | 103.12118AI | 100Bar | ||
2” NPTF | 103.11118BI | 103.12118BI | |||
50 | 2 ½” BSP | 103.11118AJ | 103.12118AJ | ||
2 ½” NPTF | 103.11118BJ | 103.12118BJ | |||
3” BSP | 103.11118AK | 103.12118AK | |||
3” NPTF | 103.11118BK | 103.12118BK |
标准型号（不锈钢）
DN | ØA | 公头 | 母头 | ||
1 ¼” BSP | 103.21127AG | 103.22127AG | |||
40 | 1 ¼” NPTF | 103.21127BG | 103.22127BG | ||
1 ½” BSP | 103.21127AH | 103.22127AH | |||
1 ½” NPTF | 103.21127BH | 103.22127BH | |||
2” BSP | 103.21128AI | 103.22128AI | 100Bar | ||
2” NPTF | 103.21128BI | 103.22128BI | |||
50 | 2 ½” BSP | 103.21128AJ | 103.22128AJ | ||
2 ½” NPTF | 103.21128BJ | 103.22128BJ | |||
3” BSP | 103.21128AK | 103.22128AK | |||
3” NPTF | 103.21128BK | 103.22128BK |
标准型号（黄铜）
DN | ØA | 公头 | 母头 | ||
1 ¼” BSP | 103.41127AG | 103.42127AG | |||
40 | 1 ¼” NPTF | 103.41127BG | 103.42127BG | ||
1 ½” BSP | 103.41127AH | 103.42127AH | |||
1 ½” NPTF | 103.41127BH | 103.42127BH | |||
2” BSP | 103.41128AI | 103.42128AI | 85 Bar | ||
2” NPTF | 103.41128BI | 103.42128BI | |||
50 | 2 ½” BSP | 103.41128AJ | 103.42128AJ | ||
2 ½” NPTF | 103.41128BJ | 103.42128BJ | |||
3” BSP | 103.41128AK | 103.42128AK | |||
3” NPTF | 103.41128BK | 103.42128BK |
防尘帽
DN | ØA | 订货号 | ØB | L | D |
40 | 60 | 103.6407AA | 70 | 60 | 609,5 |
50 | 78 | 103.6408AA | 98 | 65 | 575,5 |
防尘盖
DN | ØA | 订货号 | ØB | L | D |
40 | 75 | 103.6307AA | 68 | 26 | 609,5 |
50 | 105 | 103.6308AA | 98 | 32,4 | 575,5 |
标准订货型号（单向阀式阀芯）
DN | ØA | 公头 | 母头 | ||
06 | ¼” BSP | 104.11111AB | 104.12111AB | 350Bar | |
¼” NPTF | 104.11111BB | 104.12111AB | |||
9/16” 18ORB | 104.11111GC | 104.12111GC | |||
10 | ⅜” BSP | 104.11112AC | 104.12112AC | 300Bar | |
⅜” NPTF | 104.11112BC | 104.12112BC | |||
½” BSP | 101.11113AD | 101.12113AD | |||
13 | ½” NPTF | 101.11113BD | 101.12113BD | 300Bar | |
¾” - 16ORB | 101.11113GF | 101.12113GF | |||
⅞”- 14ORB | 101.11113GH | 101.12113GH | |||
20 | ¾” BSP | 104.11114AE | 104.12114AE | 250Bar | |
¾” NPTF | 104.11114BE | 104.12114BE | |||
25 | 1” BSP | 104.11115AF | 104.12115AF | 220Bar | |
1” NPTF | 104.11115BF | 104.12115BF | |||
标准订货型号（钢珠式阀芯）
DN | ØA | 公头 | 母头 | ||
06 | ¼” BSP | 104.11211AB | 104.12211AB | 350Bar | |
¼” NPTF | 104.11211BB | 104.12211AB | |||
9/16” 18ORB | 104.11211GC | 104.12211GC | |||
10 | ⅜” BSP | 104.11212AC | 104.12212AC | 300Bar | |
⅜” NPTF | 104.11212BC | 104.12212BC | |||
½” BSP | 101.11213AD | 101.12213AD | |||
13 | ½” NPTF | 101.11213BD | 101.12213BD | 300Bar | |
¾” - 16ORB | 101.11213GF | 101.12213GF | |||
⅞”- 14ORB | 101.11213GH | 101.12213GH | |||
20 | ¾” BSP | 104.11214AE | 104.12214AE | 250Bar | |
¾” NPTF | 104.11214BE | 104.12214BE | |||
25 | 1” BSP | 104.11215AF | 104.12215AF | 220Bar | |
1” NPTF | 104.11215BF | 104.12215BF | |||
防尘盖
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
* | * | * | |||||
06 | 104.5311AA | * | * | ||||
10 | 104.5312AA | * | * | * | * | * | |
13 | 101.5313AA | 101.5323AA | 101.5333AA | 101.5343AA | 101.5353AA | 101.5363AA | |
20 | 104.5314AA | * | * | * | * | * | |
25 | 104.5315AA | * | * | * | * | * |
防尘帽
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
* | * | * | |||||
06 | 104.5411AA | * | * | ||||
10 | 104.5412AA | * | * | * | * | * | |
13 | 101.5413AA | 101.5423AA | 101.5433AA | 101.5443AA | 101.5453AA | 101.5463AA | |
20 | 104.5414AA | * | * | * | * | * | |
25 | 104.5415AA | * | * | * | * | * |
标准公头型号
DN | ØA | 公头 | ||
½” BSP | 101.11113AD | |||
13 | ½” NPTF | 101.11113BD | 300Bar | |
M22x1,5 | 101.11113NG | |||
¾” - 16ORB | 101.11113GF | |||
⅞” 14ORB | 101.11113GH |
标准母头型号
DN | ØA | 母头 | ||
13 | ½” BSP | 105.12113AD | 300Bar | |
½” NPTF | 105.12113BD | |||
M22x1,5 | 105.12113NG |
防尘盖
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
101.5322AA | 101.5332AA | 101.5362AA | |||||
10 | 101.5312AA | 101.5342AA | 101.5352AA | ||||
13 | 101.5313AA | 101.5323AA | 101.5333AA | 101.5343AA | 101.5353AA | 101.5363AA |
DN | 红 | 蓝 | 黄 | 绿 | 黑 | 白 | |
101.5422AA | 101.5432AA | 101.5462AA | |||||
10 | 101.5412AA | 101.5442AA | 101.5452AA | ||||
13 | 101.5413AA | 101.5423AA | 101.5433AA | 101.5443AA | 101.5453AA | 101.5463AA |
DN | ØA | 订货号 | |
20 | ¾” NPTF | 106.11114BE | 250Bar |
20 | ¾” NPTF | 106.11214BE* | 250Bar |
DN | ØA | 订货号 | |
20 | ¾” NPTF | 106.12114BE | 250Bar |
20 | ¾” NPTF | 106.12214BE* | 250Bar |
标准公头型号
DN | ØA | ØT | 订货号 | ||
M12x1,5 | 6L | 102.11112JB | |||
M14x1,5 | 8L | 102.11112JC | |||
M16x1,5 | 10L | 102.11112JD | |||
10 | M18x1,5 | 12L | 102.11112JE | 270Bar | |
M16x1,5 | 8S | 102.11112KD | |||
M18x1,5 | 10S | 102.11112KE | |||
M20x1,5 | 12S | 102.11112KF | |||
⅜” BSP | - | 102.11112AN | |||
M14x1,5 | 8L | 102.11113JC | |||
M16x1,5 | 10L | 102.11113JD | |||
M18x1,5 | 12L | 102.11113JE | |||
M22x1,5 | 15L | 102.11113JG | |||
13 | M26x1,5 | 18L | 102.11113JI | 250Bar | |
M18x1,5 | 10S | 102.11113KE | |||
M20x1,5 | 12S | 102.11113KF | |||
M22x1,5 | 14S | 102.11113KG | |||
M24x1,5 | 16S | 102.11113KH | |||
M30x2 | 20S | 102.11113KJ |
标准母头型号
DN | ØA | ØT | 订货号 | |||
M12x1,5 | 6L | 107.12112JB | ||||
M14x1,5 | 8L | 107.12112JC | ||||
M16x1,5 | 10L | 107.12112JD | ||||
10 | M18x1,5 | 12L | 107.12112JE | 270Bar | ||
M16X1,5 | 8S | 107.12112KD | ||||
M18x1,5 | 10S | 107.12112KE | ||||
M20x1,5 | 12S | 107.12112KF | ||||
⅜” BSP | - | 107.12112AN | ||||
M14x1,5 | 8L | 107.12113JC | ||||
M16x1,5 | 10L | 107.12113JD | ||||
M18x1,5 | 12L | 107.12113JE | ||||
M22x1,5 | 15L | 107.12113JG | ||||
13 | M26x1,5 | 18L | 107.12113JI | 250Bar | ||
M18x1,5 | 10S | 107.12113KE | ||||
M20x1,5 | 12S | 107.12113KF | ||||
M22x1,5 | 14S | 107.12113KG | ||||
M24x1,5 | 16S | 107.12113KH | ||||
M30x2 | 20S | 107.12113KJ |
标准公头型号
DN | ØA | ØT | 订货号 | ||
M12x1,5 | 6L | 102.11112LB | |||
M14x1,5 | 8L | 102.11112LC | |||
10 | M16x1,5 | 10L | 102.11112LD | 270Bar | |
M18x1,5 | 12L | 102.11112LE | |||
M16x1,5 | 8S | 102.11112MD | |||
M18x1,5 | 10S | 102.11112ME | |||
M20x1,5 | 12S | 102.11112MF | |||
M14x1,5 | 8L | 102.11113LC | |||
M16x1,5 | 10L | 102.11113LD | |||
M18x1,5 | 12L | 102.11113LE | |||
M22x1,5 | 15L | 102.11113LG | |||
13 | M26x1,5 | 18L | 102.11113LI | 250Bar | |
M18x1,5 | 10S | 102.11113ME | |||
M20x1,5 | 12S | 102.11113MF | |||
M22x1,5 | 14S | 102.11113MG | |||
M24x1,5 | 16S | 102.11113MH | |||
M30x2 | 20S | 102.11113MJ |
标准母头型号
DN | ØA | ØT | 订货号 | ||
M12x1,5 | 6L | 107.12112LB | |||
M14x1,5 | 8L | 107.12112LC | |||
10 | M16x1,5 | 10L | 107.12112LD | 270Bar | |
M18x1,5 | 12L | 107.12112LE | |||
M16x1,5 | 8S | 107.12112MD | |||
M18x1,5 | 10S | 107.12112ME | |||
M20x1,5 | 12S | 107.12112MF | |||
M14x1,5 | 8L | 107.12113LC | |||
M16x1,5 | 10L | 107.12113LD | |||
M18x1,5 | 12L | 107.12113LE | |||
M22x1,5 | 15L | 107.12113LG | |||
13 | M26x1,5 | 18L | 107.12113LI | 250Bar | |
M18x1,5 | 10S | 107.12113ME | |||
M20x1,5 | 12S | 107.12113MF | |||
M22x1,5 | 14S | 107.12113MG | |||
M24x1,5 | 16S | 107.12113MH | |||
M30x2 | 20S | 107.12113MJ |
标准公头型号 | ||||
DN | ØA | 订货号 | ||
¼” BSP | 102.11112AB | |||
¼” NPTF | 102.11112BB | |||
10 | ⅜” BSP | 102.11112AC | 270Bar | |
⅜” NPTF | 102.11112BC | |||
M16x1,5 | 102.11112ND | |||
M18x1,5 | 102.11112NE | |||
⅜” BSP | 102.11113AC | |||
½” BSP | 102.11113AD | |||
¾” NPTF | 102.11113BE | |||
M14x1,5 | 102.11113NC | |||
13 | M16x1,5 | 102.11113ND | 250Bar | |
M18x1,5 | 102.11113NE | |||
M22x1,5 | 102.11113NG | |||
¾” -16ORB | 102.11113GF | |||
⅞”-14ORB | 102.11113GH | |||
* ¾” -16ORB | 102.11113GFA | |||
标准母头型号 | ||||
DN | ØA | 订货号 | ||
¼” BSP | 107.12112AB | |||
¼” NPTF | 107.12112BB | |||
10 | ⅜” BSP | 107.12112AC | 270Bar | |
⅜” NPTF | 107.12112BC | |||
M16x1,5 | 107.12112ND | |||
M18x1,5 | 107.12112NE | |||
⅜” BSP | 107.12113AC | |||
½” BSP | 107.12113AD | |||
¾” NPTF | 107.12113BE | |||
M14x1,5 | 107.12113NC | |||
13 | M16x1,5 | 107.12113ND | 250Bar | |
M18,1,5 | 107.12113NE | |||
M22x1,5 | 107.12113NG | |||
¾” -16ORB | 107.12113GF | |||
⅞”-14ORB | 107.12113GH | |||
* ¾” -16ORB | 107.12113GFA | |||
标准公头型号
DN | ØA | ØT | 订货号 | ||
M18x1,5 | 12L | 120.11113JE | |||
13 | M20x1,5 | Ø13,5 | 120.11113KFA | 150Bar | |
M22x,15 | 15L | 120.11113JG | |||
½” BSP M. | - | 120.11113AO | |||
½” BSP | - | 120.11113AD |
标准母头型号
DN | ØA | 订货号 | ||
⅜” BSP | 120.12113AC | |||
13 | ½” BSP | 120.12113AD | 150 Bar | |
M18x1.5 | 120.12113NE | |||
M20x1.5 | 120.12113NF |
订货号 | 扩展序列号 010. 最小采 |
购数量250个。 | |
122.11113JE | |
122.11113KFA 250Bar | |
122.11113HFA | |
22.11113AO 250Ba
122.12113NE 250Bar
122.12113AOA | 250Bar |
122.11113GFA 250Ba
122.11113JDA 250Ba
122.11113JGA 250Bar
122.11113LGA 250Bar
标准公头型号 | |||||
DN | ØA | 订货号 | |||
10 | ⅜” BSP | 125.11112AC | 350Bar | ||
⅜” NPTF | 125.11112BC | ||||
13 | ½” BSP | 125.11113AD | 350Bar | ||
½” NPTF | 125.11113BD | ||||
20 | ¾” BSP | 125.11114AE | 280Bar | ||
¾” NPTF | 125.11114BE | ||||
25 | 1” BSP | 125.11115AF | 250Bar | ||
1” NPTF | 125.11115BF | ||||
标准母头型号 | ||||
DN | ØA | 订货号 | ||
10 | ⅜” BSP | 125.12112AC | 350Bar | |
⅜” NPTF | 125.12112BC | |||
13 | ½” BSP | 125.12113AD | 350Bar | |
½” NPTF | 125.12113BD | |||
20 | ¾” BSP | 125.12114AE | 280Bar | |
¾” NPTF | 125.12114BE | |||
25 | 1” BSP | 125.12115AF | 250Bar | |
1” NPTF | 125.12115BF | |||
126.11002AC | |
350Bar | |
126.11002AC011 | |
126.21002AC 300 Bar | |
126.12022AC011 | 350Bar |
126.21002AC | 90 Bar |
126.42022AC011 | |
126.22022AC | 300 Bar |
公头
DN | ØA | CH1 | C | ØF | L | 订货号 | |
25 | 1” BSP | 41 | 63 | 36,20 | 126 | 127.11115AF | 250Bar |
母头
DN | ØA | CH2 | B | ØD | L | 订货号 | |
25 | 1” BSP | 41 | 98 | 58 | 126 | 127.12115AF | 250 Bar |
公头
DN | ØA | CH1 | C | ØF | L | 订货号 | |
20 | ¾” BSP | 36 | 59 | 28 | 117,50 | 128.11214AE | 250Bar |
25 | 1” BSP | 41 | 72 | 36,50 | 138 | 128.11215AF | 230Bar |
母头
DN | ØA | CH2 | C | ØD | L | 订货号 | |
20 | ¾” BSP | 38 | 83,50 | 45,50 | 117,50 | 128.12214AE | 250Bar |
母头
DN | ØA | CH2 | C | ØD | L | 订货号 | |
25 | 1” BSP | 41 | 105 | 57,50 | 138 | 128.12215AF | 230Bar |
标准型号
DN | ØA | 订货号 | CH2 | L2 | ØD | L | ||
06 | ¼” BSP | 129.12111AB | 350Bar | 19 | 51 | 26 | 72 | |
¼” NPTF | 129.12111BB | |||||||
10 | ⅜” BSP | 129.12112AC | 24 | 58,50 | 32 | 81 | ||
⅜” NPTF | 129.12112BC | 300Bar | ||||||
⅜” BSPT | 129.12112DC | |||||||
13 | ½” BSP | 129.12113AD | 30 | 63,50 | 38 | 87,50 | ||
½” NPTF | 129.12113BD | 300Bar | ||||||
½” BSPT | 129.12113DD | |||||||
20 | ¾” BSP | 129.12114AE | 250Bar | 38 | 83,50 | 46 | 112 | |
¾” NPTF | 129.12114BE | |||||||
25 | 1” BSP | 129.12115AF | 230Bar | 46 | 97 | 55 | 126 | |
1” NPTF | 129.12115BF | |||||||
32 | 1” ¼ BSP | 129.12116AG | 230Bar | 50 | 117 | 70 | 150 | |
1” ¼ NPTF | 129.12116BG | |||||||
40 | 1” ½” BSP | 129.12117AH | 200Bar | 60 | 133 | 84,50 | 167 | |
1” ½” NPTF | 129.12117BH | |||||||
50 | 2” BSP | 129.12118AI | 130Bar | 75 | 165 | 100 | 210 | |
2” NPTF | 129.12118BI | |||||||
标准型号
DN | ØA | 公头 | 母头 | ||
07 | ¼” BSP | 130.11111AB | 130.12111AB | 300Bar | |
¼” NPTF | 130.11111BB | 130.12111BB | |||
⅜” BSP | 130.11112AC | 130.12112AC | |||
⅜” NPTF | 130.11112BC | 130.12112BC | |||
09 | ½ ” BSP | 130.11112AD | 130.12112DC | 300Bar | |
½ ” NPTF | 130.11112BD | 130.12112BD | |||
¾ ”-16ORB | 130.11112GF | 130.12112GF |
”-14ORB 130.11112GH 130.12112GH
½” BSP | 130.11113AD | 130.12113AD | |||
½” NPTF | 130.11113BD | 130.12113BD | |||
13 | ¾” BSP | 130.11113AE | 130.12113AE | 250Bar | |
¾” NPTF | 130.11113BE | 130.12113BE | |||
⅞” - 14ORB | 130.11113GH | 130.11113GH | |||
1 1/16” 12ORB 130.11113GK | 130.12113GK | ||||
15 | ¾” BSP | 130.11114AE | 130.12114AE | 250Bar | |
¾” NPTF | 130.11114BE | 130.12114BE | |||
1 1/16”-12ORB 130.11114GK | 130.12114GK | ||||
17 | 1” BSP | 130.11115AF | 130.12115AF | 250Bar | |
1” NPTF | 130.11115BF | 130.12115BF | |||
1 5/16”-12ORB 130.11115GO | 130.12115GO | ||||
21 | 1 ¼” BSP | 130.11116AG | 130.12116AG | 250Bar | |
1 ¼” NPTF | 130.11116BG | 130.12116BG | |||
30 | 1 ½” BSP | 130.11117AH | 130.12117AH | 200Bar | |
1 ½” NPTF | 130.11117BH | 130.12117BH | |||
45 | 2” BSP | 130.11118AI | 130.12118AI | 200Bar | |
标准型号
DN | ØA | 公头订货号 | 母头订货号 | ||
07 | ¼” BSP | 130.21111AB | 130.22111AB | 225Bar | |
¼” NPTF | 130.21111BB | 130.22111BB | |||
⅜” BSP | 130.21112AC | 130.22112AC | |||
⅜” NPTF | 130.21112BC | 130.22112BC | |||
09 | ½ ” BSP | 130.21112AD | 130.22112DC | 225Bar | |
½ ” NPTF | 130.21112BD | 130.22112BD | |||
¾ ”-16ORB | 130.21112GF | 130.22112GF |
”-14ORB 130.21112GH 130.22112GH
½” BSP | 130.21113AD | 130.22113AD | |||
½” NPTF | 130.21113BD | 130.22113BD | |||
13 | ¾” BSP | 130.21113AE | 130.22113AE | 200Bar | |
¾” NPTF | 130.21113BE | 130.22113BE | |||
⅞” - 14ORB | 130.21113GH | 130.21113GH | |||
1 1/16” 12ORB | 130.21113GK | 130.22113GK | |||
15 | ¾” BSP | 130.21114AE | 130.22114AE | 200Bar | |
¾” NPTF | 130.21114BE | 130.22114BE | |||
1 1/16”-12ORB 130.21114GK | 130.22114GK | ||||
17 | 1” BSP | 130.21115AF | 130.22115AF | 125Bar | |
1” NPTF | 130.21115BF | 130.22115BF | |||
1 5/16”-12ORB 130.21115GO | 130.22115GO | ||||
21 | 1 ¼” BSP | 130.21116AG | 130.22116AG | 125Bar | |
1 ¼” NPTF | 130.21116BG | 130.22116BG | |||
30 | 1 ½” BSP | 130.21117AH | 130.22117AH | 90Bar | |
1 ½” NPTF | 130.21117BH | 130.22117BH | |||
45 | 2” BSP | 130.21118AI | 130.22118AI | 90Bar | |
标准型号
DN | ØA | 公头 | 母头 | ||
07 | ¼” BSP | 131.11111AB | 131.12111AB | 500Bar | |
¼” NPTF | 131.11111BB | 131.12111BB | |||
⅜” BSP | 131.11112AC | 131.12112AC | |||
⅜” NPTF | 131.11112BC | 131.12112BC | |||
09 | ½ ” BSP | 131.11112AD | 131.12112DC | 350Bar | |
½ ” NPTF | 131.11112BD | 131.12112BD | |||
¾ ”-16ORB | 131.11112GF | 131.12112GF |
”-14ORB 131.11112GH 131.12112GH
½” BSP | 131.11113AD | 131.12113AD | |||
½” NPTF | 131.11113BD | 131.12113BD | |||
13 | ¾” BSP | 131.11113AE | 131.12113AE | 350Bar | |
¾” NPTF | 131.11113BE | 131.12113BE | |||
⅞” - 14ORB | 131.11113GH | 131.11113GH | |||
1 1/16” 12ORB 131.11113GK | 131.12113GK | ||||
15 | ¾” BSP | 131.11114AE | 131.12114AE | 350Bar | |
¾” NPTF | 131.11114BE | 131.12114BE | |||
1 1/16”-12ORB 131.11114GK | 131.12114GK | ||||
17 | 1” BSP | 131.11115AF | 131.12115AF | 350Bar | |
1” NPTF | 131.11115BF | 131.12115BF | |||
1 5/16”-12ORB 131.11115GO | 131.12115GO | ||||
21 | 1 ¼” BSP | 131.11116AG | 131.12116AG | 350Bar | |
1 ¼” NPTF | 131.11116BG | 131.12116BG | |||
30 | 1 ½” BSP | 131.11117AH | 131.12117AH | 350Bar | |
1 ½” NPTF | 131.11117BH | 131.12117BH | |||
标准型号
DN | ØA | 公头 | 母头 | ||
07 | ¼” BSP | 131.21111AB | 131.22111AB | 500Bar | |
¼” NPTF | 131.21111BB | 131.22111BB | |||
⅜” BSP | 131.21112AC | 131.22112AC | |||
⅜” NPTF | 131.21112BC | 131.22112BC | |||
09 | ½ ” BSP | 131.21112AD | 131.22112DC | 350Bar | |
½ ” NPTF | 131.21112BD | 131.22112BD | |||
¾ ”-16ORB | 131.21112GF | 131.22112GF |
”-14ORB 131.21112GH 131.22112GH
½” BSP | 131.21113AD | 131.22113AD | |||
½” NPTF | 131.21113BD | 131.22113BD | |||
13 | ¾” BSP | 131.21113AE | 131.22113AE | 350Bar | |
¾” NPTF | 131.21113BE | 131.22113BE | |||
⅞” - 14ORB | 131.21113GH | 131.21113GH | |||
1 1/16” 12ORB | 131.21113GK | 131.22113GK | |||
15 | ¾” BSP | 131.21114AE | 131.22114AE | 350Bar | |
¾” NPTF | 131.21114BE | 131.22114BE | |||
1 1/16”-12ORB 131.21114GK | 131.22114GK | ||||
17 | 1” BSP | 131.21115AF | 131.22115AF | 350Bar | |
1” NPTF | 131.21115BF | 131.22115BF | |||
1 5/16”-12ORB 131.21115GO | 131.22115GO | ||||
21 | 1 ¼” BSP | 131.21116AG | 131.22116AG | 350Bar | |
1 ¼” NPTF | 131.21116BG | 131.22116BG | |||
30 | 1 ½” BSP | 131.21117AH | 131.22117AH | 350Bar | |
1 ½” NPTF | 131.21117BH | 131.22117BH | |||
公头（碳钢）
DN | ØA | CH1 | C | ØF | L | 订货号 | |
06 | ¼” BSP | 19 | 25 | 14,10 | 45,10 | 140.11001AB | 700 Bar |
10 | ⅜” BSP | 22 | 28 | 18,90 | 48,50 | 140.11002AC | 600 Bar |
13 | ½” BSP | 27 | 33 | 20,40 | 55,50 | 140.11003AD | 500 Bar |
母头（碳钢）
DN | ØA | CH2 | B | ØD | L | 订货号 | |
06 | ¼” BSP | 22 | 35 | 29,50 | 45,10 | 140.12011AB | 700 Bar |
10 | ⅜” BSP | 27 | 38 | 34 | 48,50 | 140.12012AC | 600 Bar |
13 | ½” BSP | 32 | 45 | 39,50 | 55,50 | 140.12013AD | 500 Bar |
公头
DN | ØA | CH1 | ØF | ØP | L | 订货号 | |
2/38 | ¼”BSP M. | 14 | 9,60 | 6 | 26 | 190.41001AM | |
3/17 | ¼”BSP M. | 13,30 | 8 | 31 | 190.41002AM | ||
⅜” BSP M. | 27 | 190.41002AN |
公头
DN | ØA | CH1 | ØF | ØP | L | 订货号 | |
2/38 | ¼”BSP M. | 19 | 9,60 | 6 | 26 | 190.41001AB | |
3/17 | ¼” BSP | 17 | 13,30 | 8 | 31 | 190.41002AB | |
⅜” BSP M. | 27 | 34 | 190.41002AC |
母头（ 180º ）
DN | ØD | B | ØC | ØP | L | 订货号 |
2/38 | 17 | 56 | 10 | 6 | 71,50 | 190.42031XX |
3/17 | 23,50 | 57 | 13,30 | 8 | 82 | 190.42032XX |
母头（ 90º | ） | ||||||||||||||||
DN | ØD | B1 | B2 | ØC | ØP | L | 订货号 | ||||||||||
2/38 | * | * | * | * | * | * | 190.42031XY | ||||||||||
3/17 | 24 | 42 | 48 | 13,30 | 8 | 60 | 190.42032XY | ||||||||||
公头
DN | ØA1 | ØA2 | CH1 | C | ØF | L | 订货号 | |
20 | ¾” BSP | 1 ¼” | 46 | 78 | 44 | 138 | 201.11114AE | 250 Bar |
25 | 1” BSP | BSP | 55 | 83 | 53,60 | 148 | 201.11115AF | 230 Bar |
公头
DN | ØA2 | CH1 | B | ØF | L | 订货号 |
20 | 1” BSP | 46 | 68 | 44 | 118,50 | 201.11114AQ 250 Bar |
母头
DN | ØA1 | ØA2 | E/C | B | ØD | L | 订货号 | |
20 | ¾” BSP | 41,50 | 33 | 78 | 115 | 138 | 201.12114AE | 250 Bar |
25 | 1” BSP | 51 | 40 | 83 | 115 | 148 | 201.12115AF | 230 Bar |
母头
DN | ØA1 | E/C | ØA2 | B | ØD | L | 订货号 |
20 | 1” BSP | 33 | 41,50 | 74 | 115 | 118,50 | 201.12114AQ 250 Bar |
标准公头型号
DN | ØA1 | 订货号 | E/C | ØG | L1 | ØF | L | |
06 | ¼” NPTF | 202.11141BB | 1200Bar | * | * | * | * | * |
10 | ⅜” NPTF | 202.11142BC | 1200Bar | 24 | 1 3/16” UN 38,88 | 18,99 | 72,75 | |
标准公头型号（不锈钢）
DN | ØA1 | 订货号 | E/C | ØG | L1 | ØF | L | |
06 | ¼” NPTF | 202.21121BB | 1200Bar | * | * | * | * | * |
10 | ⅜” NPTF | 202.21122BC | 1200Bar | 24 | 1 3/16” UN 42,50 | 18,99 | 72,75 | |
标准母头型号
DN | ØA | 订货号 | CH2 | L2 | ØE | L | |
06 | ¼” NPTF M. | 202.12141BM | 1200Bar | * | * | * | * |
10 | ⅜” NPTF M. | 202.12142BN | 1200Bar | 22 | 45,50 | 34,50 | 72,75 |
标准母头型号（不锈钢）
DN | ØA | 订货号 | CH2 | L2 | ØE | L | |
06 | ¼” NPTF M. | 202.22121BM | 1200Bar | * | * | * | * |
10 | ⅜” NPTF M. | 202.22122BN | 1200Bar | 22 | 45,50 | 34,50 | 72,75 |
标准公头型号
DN | ØA | 订货号 | E/C | ØG | L1 | ØF | L | |
06 | ¼” NPTF | 202.11201BB | 700Bar | 19 | 1”UN | 34 | 15,85 | 75,5 |
10 | ⅜” NPTF | 202.11202BC | 700Bar | 24 | 1 3/16” UN 38,88 | 18,99 | 87,14 | |
标准公头型号（不锈钢） | ||||||||
DN | ØA | 订货号 | E/C | ØG | L1 | ØF | L | |
06 | ¼” NPTF | 202.21201BB | 700Bar | 19 | 1”UN | 34 | 15,85 | 75,5 |
10 | ⅜” NPTF | 202.21202BC | 700Bar | 24 | 1 3/16” UN 38,88 | 18,99 | 87,14 | |
标准母头型号
DN | ØA | 订货号 | CH2 | L2 | ØD | L | |
06 | ¼” NPTF M. | 202.12241BM | 700Bar | 19 | 53 | 30 | 75,5 |
10 | ⅜” NPTF M. | 202.12242BN | 700Bar | 24 | 64 | 34,50 | 87,14 |
标准母头型号（不锈钢） | |||||||
DN | ØA | 订货号 | CH2 | L2 | ØD | L | |
06 | ¼” NPTF M. | 202.22221BM | 700Bar | 19 | 53 | 30 | 75,5 |
10 | ⅜” NPTF M. | 202.22222BN | 700Bar | 24 | 64 | 34,50 | 87,14 |
标准型号
DN | ØA | 公头订货号 | 母头订货号 | ||
06 | ¼” BSP | 203.11111AB | 203.12111AB | 950Bar | |
¼” NPTF | 203.11111BB | 203.12111BB | |||
10 | ⅜” BSP | 203.11112AC | 203.12112AC | ||
⅜” NPTF | 203.11112BC | 203.12112BC | 750Bar | ||
13 | ½” BSP | 203.11113AD | 203.12113AD | ||
½” NPTF | 203.11113BD | 203.12113BD | |||
20 | ¾” BSP | 203.11114AE | 203.12114AE | 650Bar | |
¾” NPTF | 203.11114BE | 203.12114BE | |||
25 | 1” BSP | 203.11115AF | 203.12115AF | ||
1” NPTF | 203.11115BF | 203.12115BF | 450Bar | ||
32 | 1 ¼” BSP | 203.11116AG | 203.12116AG | ||
1 ¼” NPTF | 203.11116BG | 203.12116BG | |||
40 | 1 ½” BSP | 203.11117AH | 203.12117AH | ||
1 ½” NPTF | 203.11117BH | 203.12117BH | 300Bar | ||
50 | 2” BSP | 203.11118AI | 203.12118AI | ||
2” NPTF | 203.11118BI | 203.12118BI | |||
公头
DN | ØA | E/C | CH2 | B | ØF | ØD | L | 订货号 |
13 | ½” BSP | 25 | 36 | 49,5 | 21,80 | 30,50 | 88 | 204.11113AD 400 Bar |
母头
DN | ØA | E/C | B | ØD | L | 订货号 | |
13 | ½” BSP | 27 | 69,5 | 33 | 88 | 204.12113AD | 400Bar |
标准型号
DN | ØA | 公头订货号 | 母头订货号 | ||
06 | ¼” BSP | 205.11111AB | 205.12111AB | ||
¼” NPTF | 205.11111BB | 205.12111BB | |||
M14x1,5 | 205.11111NC | 205.12111NC | |||
¼” BSP | 205.11112AB | 205.12112AB | 450Bar | ||
10 | ⅜” BSP | 205.11112AC | 205.12112AC | ||
⅜” NPTF | 205.11112BC | 205.12112BC | |||
M16x1,5 | 205.11112ND | 205.12112ND | |||
⅜” BSP | 205.11113AC | 205.12113AC | |||
½” BSP | 205.11113AD | 205.12113AD | |||
13 | ½” NPTF | 205.11113BD | 205.12113BD | ||
M18x1,5 | 205.11113NE | 205.12113NE | |||
M22x1,5 | 205.11113NG | 205.12113NG | 400Bar | ||
¾” -16ORB 205.11113GF 205.12113GF | |||||
⅞” -14ORB 205.11113GH 205.12113GH | |||||
¾” BSP | 205.11114AE | 205.12114AE | |||
¾” NPTF 205.11114BE 205.12114BE M22x1,5 205.11114NG 205.12114NG
25 | ¾” BSP | 205.11115AE | 205.12115AE | ||
1” BSP | 205.11115AF | 205.12115AF | |||
1” NPTF | 205.11115BF | 205.12115BF | |||
1 ¼” BSP | 205.11116AG | 205.12116AG | 300Bar | ||
32 | 1 ¼” NPTF | 205.11116BG | 205.12116BG | ||
1 ½” BSP | 205.11116AH | 205.12116AH | |||
1 ½” NPTF | 205.11116BH | 205.12116BH | |||
DN | ØA | ØT | 订货号 | |
06 | M12x1,5 | 6L | 205.11111JB | 450Bar |
M14x1,5 | 8L | 205.11111JC | ||
⅜” BSP M. | * | 205.11112AN | ||
M14x1,5 | 8L | 205.11112JC | ||
10 | M16x1,5 | 10L | 205.11112JD | 450Bar |
M16x1,5 | 8S | 205.11112KD | ||
M18x1,5 | 10S | 205.11112KE | ||
M20x1,5 | 12S | 205.11112KF | ||
M14x1,5 | 8L | 205.11113JC | ||
M16x1,5 | 10L | 205.11113JD | ||
M18x1,5 | 12L | 205.11113JE | ||
13 | M22x1,5 | 15L | 205.11113JG | 400Bar |
M26x1,5 | 18L | 205.11113JI | ||
M18x1,5 | 10S | 205.11113KE | ||
M20x1,5 | 12S | 205.11113KF | ||
M22x1,5 | 14S | 205.11113KG | ||
M24x1,5 | 16S | 205.11113KH | ||
M18x1,5 | 12l | 205.11114JE | ||
M22x1,5 | 15L | 205.11114JG | ||
20 | M26x1,5 | 18L | 205.11114JI | 400Bar |
M30x2 | 22L | 205.11114JJ | ||
M24x1,5 | 16S | 205.11114KH | ||
M30x2 | 20S | 205.11114KJ | ||
M26x1,5 | 18L | 205.11115JI | ||
M30x2 | 22L | 205.11115JJ | ||
M36x2 | 28L | 205.11115JK | ||
25 | M45x2 | 35L | 205.11115JM | 300Bar |
M30x2 | 20S | 205.11115KJ | ||
M36x2 | 25S | 205.11115KK | ||
M42x2 | 30S | 205.11115KL | ||
M52x2 | 38S | 205.11115KN | ||
32 | M42x2 | 30S | 205.11116KL | 300Bar |
M52x2 | 38S | 205.11116KN | ||
DN | ØA | ØT | 订货号 | |
06 | M12x1,5 | 6L | 205.12111JB | 450Bar |
M14x1,5 | 8L | 205.12111JC | ||
⅜” BSP M. | * | 205.12112AN | ||
M14x1,5 | 8L | 205.12112JC | ||
10 | M16x1,5 | 10L | 205.12112JD | 450Bar |
M16x1,5 | 8S | 205.12112KD | ||
M18x1,5 | 10S | 205.12112KE | ||
M20x1,5 | 12S | 205.12112KF | ||
M14x1,5 | 8L | 205.12113JC | ||
M16x1,5 | 10L | 205.12113JD | ||
M18x1,5 | 12L | 205.12113JE | ||
13 | M22x1,5 | 15L | 205.12113JG | 400Bar |
M26x1,5 | 18L | 205.12113JI | ||
M18x1,5 | 10S | 205.12113KE | ||
M20x1,5 | 12S | 205.12113KF | ||
M22x1,5 | 14S | 205.12113KG | ||
M24x1,5 | 16S | 205.12113KH | ||
M18x1,5 | 12l | 205.12114JE | ||
M22x1,5 | 15L | 205.12114JG | ||
20 | M26x1,5 | 18L | 205.12114JI | 400Bar |
M30x2 | 22L | 205.12114JJ | ||
M24x1,5 | 16S | 205.12114KH | ||
M30x2 | 20S | 205.12114KJ | ||
M26x1,5 | 18L | 205.12115JI | ||
M30x2 | 22L | 205.12115JJ | ||
M36x2 | 28L | 205.12115JK | ||
25 | M45x2 | 35L | 205.12115JM | 300Bar |
M30x2 | 20S | 205.12115KJ | ||
M36x2 | 25S | 205.12115KK | ||
M42x2 | 30S | 205.12115KL | ||
M52x2 | 38S | 205.12115KN | ||
32 | M42x2 | 30S | 205.12116KL | 300Bar |
M52x2 | 38S | 205.12116KN | ||
DN | ØA | ØT | 订货号 | |
06 | M12x1,5 | 6L | 205.11111LB | 450Bar |
M14x1,5 | 8L | 205.11111LC | ||
M14x1,5 | 8L | 205.11112LC | ||
M16x1,5 | 10L | 205.11112LD | ||
10 | M16x1,5 | 8S | 205.11112MD | 450Bar |
M18x1,5 | 10S | 205.11112ME | ||
M20x1,5 | 12S | 205.11112MF | ||
M14x1,5 | 8L | 205.11113LC | ||
M16x1,5 | 10L | 205.11113LD | ||
M18x1,,5 | 12L | 205.11113LE | ||
M22x1,5 | 15L | 205.11113LG | ||
13 | M26x1,5 | 18L | 205.11113LI | 400Bar |
M18x1,5 | 10S | 205.11113ME | ||
M20x1,5 | 12S | 205.11113MF | ||
M22x1,5 | 14S | 205.11113MG | ||
M24x1,5 | 16S | 205.11113MH | ||
M18x1,5 | 12l | 205.11114LE | ||
M22x1,5 | 15L | 205.11114LG | ||
20 | M26x1,5 | 18L | 205.11114LI | 400Bar |
M30x2 | 22L | 205.11114LJ | ||
M24x1,5 | 16S | 205.11114MH | ||
M30x2 | 20S | 205.11114MJ | ||
M26x1,5 | 18L | 205.11115LI | ||
M30x2 | 22L | 205.11115LJ | ||
M36x2 | 28L | 205.11115LK | ||
25 | M45x2 | 35L | 205.11115LM | 300Bar |
M30x2 | 20S | 205.11115MJ | ||
M36x2 | 25S | 205.11115MK | ||
M42x2 | 30S | 205.11115ML | ||
M52x2 | 38S | 205.11115MN | ||
32 | M42x2 | 30S | 205.11116ML | 300Bar |
DN | ØA | ØT | 订货号 | |
06 | M12x1,5 | 6L | 205.12111LB | 450Bar |
M14x1,5 | 8L | 205.12111LC | ||
M14x1,5 | 8L | 205.12112LC | ||
M16x1,5 | 10L | 205.12112LD | ||
10 | M16x1,5 | 8S | 205.12112MD | 450Bar |
M18x1,5 | 10S | 205.12112ME | ||
M20x1,5 | 12S | 205.12112MF | ||
M14x1,5 | 8L | 205.12113LC | ||
M16x1,5 | 10L | 205.12113LD | ||
M18x1,,5 | 12L | 205.12113LE | ||
M22x1,5 | 15L | 205.12113LG | ||
13 | M26x1,5 | 18L | 205.12113LI | 400Bar |
M18x1,5 | 10S | 205.12113ME | ||
M20x1,5 | 12S | 205.12113MF | ||
M22x1,5 | 14S | 205.12113MG | ||
M24x1,5 | 16S | 205.12113MH | ||
M18x1,5 | 12l | 205.12114LE | ||
M22x1,5 | 15L | 205.12114LG | ||
20 | M26x1,5 | 18L | 205.12114LI | 400Bar |
M30x2 | 22L | 205.12114LJ | ||
M24x1,5 | 16S | 205.12114MH | ||
M30x2 | 20S | 205.12114MJ | ||
M26x1,5 | 18L | 205.12115LI | ||
M30x2 | 22L | 205.12115LJ | ||
M36x2 | 28L | 205.12115LK | ||
25 | M45x2 | 35L | 205.12115LM | 300Bar |
M30x2 | 20S | 205.12115MJ | ||
M36x2 | 25S | 205.12115MK | ||
M42x2 | 30S | 205.12115ML | ||
M52x2 | 38S | 205.12115MN | ||
32 | M42x2 | 30S | 205.12116ML | 300Bar |
DN | ØA | ØT | REF. | |
M14x1,5 | 8L | 206.11112JC | ||
M16x1,5 | 10L | 206.11112JD | ||
10 | M18x1,5 | 12L | 206.11112JE | 400 Bar |
M18x1,5 | 10S | 206.11112KE | ||
M20x1,5 | 12S | 206.11112KF | ||
M22x1,5 | 15L | 206.11112JG | ||
M22x1,5 | 14S | 206.11112KG | ||
M18x1,5 | 12L | 206.11113JE | ||
13 | M22x1,5 | 15L | 206.11113JG | 300 Bar |
M22x1,5 | 14S | 206.11113KG | ||
M24x1,5 | 16S | 206.11113KH | ||
M26x1,5 | 18L | 206.11113JI | ||
M26x1,5 | 18L | 206.11114JI | ||
20 | M30x2 | 22L | 206.11114JJ | 320 Bar |
M30x2 | 20S | 206.11114KJ | ||
M36x2 | 25S | 206.11114KK | ||
M30x2 | 22L | 206.11115JJ | ||
25 | M30x2 | 20S | 206.11115KJ | 300 Bar |
M36x2 | 28L | 206.11115JK | ||
M36x2 | 25S | 206.11115KK | ||
M42x2 | 30S | 206.11115KL | ||
32 | M45x2 | 35L | 206.11116JM | 420 Bar |
M52x2 | 38S | 206.11116KN | ||
DN | ØA | ØT | REF. | |
M14x1,5 | 8L | 206.12112JC | ||
M16x1,5 | 10L | 206.12112JD | ||
10 | M18x1,5 | 12L | 206.12112JE | 400 Bar |
M18x1,5 | 10S | 206.12112KE | ||
M20x1,5 | 12S | 206.12112KF | ||
M22x1,5 | 15L | 206.12112JG | ||
M22x1,5 | 14S | 206.12112KG | ||
M18x1,5 | 12L | 206.12113JE | ||
13 | M22x1,5 | 15L | 206.12113JG | 300 Bar |
M22x1,5 | 14S | 206.12113KG | ||
M24x1,5 | 16S | 206.12113KH | ||
M26x1,5 | 18L | 206.12113JI | ||
M26x1,5 | 18L | 206.12114JI | ||
20 | M30x2 | 22L | 206.12114JJ | 320 Bar |
M30x2 | 20S | 206.12114KJ | ||
M36x2 | 25S | 206.12114KK | ||
M30x2 | 22L | 206.12115JJ | ||
25 | M30x2 | 20S | 206.12115KJ | 300 Bar |
M36x2 | 28L | 206.12115JK | ||
M36x2 | 25S | 206.12115KK | ||
M42x2 | 30S | 206.12115KL | ||
32 | M45x2 | 35L | 206.12116JM | 420 Bar |
M52x2 | 38S | 206.12116KN | ||
DN | D | 有安装孔 | 无安装孔 | |
¼” BSP | 402.1111AB | 402.1011AB | ||
06 | ¼” NPTF | 402.1111BB | 402.1011.BB | |
7/16”- | 402.1111GA | 402.1011GA | ||
20ORB | ||||
10 | ⅜” BSP | 402.1112AC | 402.1012AC | 500Bar |
⅜” NPTF | 402.1112BC | 402.1012BC | ||
9/16” ORB | 402.1112GC | 402.1012GC | ||
13 | ½” BSP | 402.1113AD | 402.1013AD | |
½” NPTF | 402.1113BD | 402.1013BD | ||
¾” - 16ORB 402.1113GF 402.1013GF | ||||
¾” BSP | 402.1114AE | 402.1014AE | ||
20 | ¾” NPTF | 402.1114BE | 402.1014BE | 400Bar |
1 1/16”- | 402.1114GK | 402.1014GK | ||
12ORB | ||||
” BSP | 402.1115AF | 402.1015AF | ||
1” NPTF | 402.1115BF | 402.1015BF | ||
1 ¼” BSP | 402.1115AG | 402.1015AG | ||
25 | 1 ¼” NPTF | 402.1115BG | 402.1015BG | 350Bar |
1 ½” BSP | 402.1115AH | 402.1015AH | ||
1 ½” NPTF | 402.1115BH | 402.1015BH | ||
1 5/16”- | 402.1115GO | 402.1015GO | ||
12ORB | ||||
1 ¼” BSP | 402.1016AG | |||
32 | 1 ¼” NPTF | 402.1016BG | ||
1 5/8”- | 402.1016GT | |||
12ORB | 320Bar | |||
40 | 1 ½” BSP | 402.1017AH | ||
1 ½” NPTF | 402.1017BH | |||
50 | 2” BSP | 402.1018AI | ||
2” NPTF | 402.1018BI | |||
DN | D | ØT | 有安装孔 | 无安装孔 | |
M12x1,5 | 6L | 402.1111JB | 402.1011JB | ||
06 | M14x1,5 | 8L | 402.1111JC | 402.1011JC | |
M16x1,5 | 8S | 402.1111KD | 402.1011KD | ||
M18x1,5 | 10S | 402.1111KE | 402.1011KE | ||
M16x1,5 | 10L | 402.1112JD | 402.1012JD | ||
10 | M18x1,5 | 12L | 402.1112JE | 402.1012JE | 500Bar |
M22x1,5 | 15L | 402.1112JG | 402.1012JG | ||
M20x1,5 | 12S | 402.1112KF | 402.1012KF | ||
M22x1,5 | 14S | 402.1112KG | 402.1012KG | ||
M22x1,5 | 15L | 402.1113JG | 402.1013JG | ||
13 | M26x1,5 | 18L | 402.1113JI | 402.1013JI | |
M24x1,5 | 16S | 402.1113KH | 402.1013KH | ||
M30x2 | 20S | 402.1113KJ | 402.1013KJ | ||
20 | M30x2 | 22L | 402.1114JJ | 402.1014JJ | 400Bar |
M30x2 | 20S | 402.1114KJ | 402.1014KJ | ||
M36x2 | 25S | 402.1114KK | 402.1014KK | ||
25 | M36x2 | 28L | 402.1115JK | 402.1015JK | 350Bar |
M42x2 | 30S | 402.1115KL | 402.1015KL | ||
32 | M45x2 | 35L | - | 402.1016JM | 320Bar |
M52x2 | 38S | - | 402.1016KN | ||
标准型号
DN | Ø D | 订货号 | ||
06 | ¼” BSP | 412.1011AB | 500Bar | |
¼” NPTF | 412.1011BB | |||
7/16”-20ORB | 412.1011GA | |||
10 | ⅜” BSP | 412.1012AC | 500Bar | |
⅜” NPTF | 412.1012BC | |||
9/16”-18ORB | 412.1012GC | |||
13 | ½” BSP | 412.1013AD | 500Bar | |
½” NPTF | 412.1013BD | |||
¾” - 16ORB | 412.1013GF | |||
20 | ¾” BSP | 412.1014.AE | 400Bar | |
¾” NPTF | 412.1014BE | |||
1 1/16”-12ORB | 412.1014GK | |||
12” BSP | 412.1015AF | |||
1” NPTF | 412.1015BF | |||
25 | 1 ¼” BSP | 412.1015AG | 350Bar | |
1 ¼” NPTF | 412.1015BG | |||
1 ½” BSP | 412.1015AH | |||
1 ½” NPTF | 412.1015BH | |||
1 5/16”-12ORB | 412.1015GO | |||
32 | 1 ¼” BSP | 412.1016AH | 320Bar | |
1 ¼” NPTF | 412.1016BH | |||
1 5/8”-12ORB | 412.1016GT | |||
40 | 1 ½” BSP | 412.1017AH | 320Bar | |
1 ½” NPTF | 412.1017BH | |||
50 | 2” BSP | 412.1018AI | 320Bar | |
2” NPTF | 412.1018BI | |||
DN | Ø D | Ø T | 订货号 | |
M12X1.5 | 6L | 412.1011JB | ||
06 | M14X1.5 | 8L | 412.1011JC | 500Bar |
M16X1.5 | 8S | 412.1011KD | ||
M18X1.5 | 10S | 412.1011KE | ||
M16x1.5 | 10L | 412.1012JD | ||
10 | M18X1.5 | 12L | 412.1012JE | 500Bar |
M22X1.5 | 15L | 412.1012JG | ||
M20X1.5 | 12S | 412.1012KF | ||
M22X1.5 | 14S | 412.1012KG | ||
M22X1.5 | 15L | 412.1013JG | ||
13 | M26X1.5 | 18L | 412.1013JI | 500Bar |
M24X1.5 | 16S | 412.1013KH | ||
M30X2 | 20S | 412.1013KJ | ||
20 | M30X2 | 22L | 412.1014JJ | 400Bar |
M30X2 | 20S | 412.1014KJ | ||
M36X2 | 25S | 412.1014KK | ||
25 | M36X2 | 28L | 412.1015JK | 350Bar |
M42X2 | 30S | 412.1015KL | ||
32 | M45X2 | 35L | 412.1016JM | 320Bar |
M52X2 | 38S | 412.1016KN | ||
DN | D / F | 有安装孔 | 无安装孔 |
06 | ¼” BSP | 432.1111AB | 432.1011AB |
¼” NPTF | 432.1111BB | 432.1011BB | |
7/16”-20ORB | 432.1111GA | 432.1011GA | |
10 | ⅜” BSP | 432.1111AC | 432.1011AC |
⅜” NPTF | 432.1112BC | 432.1012BC | |
9/16” ORB | 432.1112GC | 432.1012GC | |
13 | ½” BSP | 432.1112AD | 432.1012AD |
½” NPTF | 432.1112BD | 432.1012BD | |
¾” - 16ORB | 432.1112GF | 432.1012GF | |
¾” BSP | 432.1113AE | 432.1013AE | |
20 | ¾” NPTF | 432.1113BE | 432.1013BE |
1 1/16”-12ORB | 432.1113GK | 432.1013GK | |
1” BSP | 432.1113AF | 432.1013AF | |
1” NPTF | 432.1114BF | 432.1014BF | |
25 | 1 ¼” BSP | 432.1114AG | 432.1014AG |
1 ¼” NPTF | 432.1114BG | 432.1014BG | |
1 ½” BSP | 432.1115AH | 432.1015AH | |
1 ½” NPTF | 432.1115BH | 432.1015BH | |
1 5/16” -12ORB | 432.1115GO | 432.1015GO |
DN | D | ØT | 有安装孔 | 无安装孔 | |
M12x1,5 | 6L | 432.1111JB | 432.1011JB | ||
06 | M14x1,5 | 8L | 432.1111JC | 432.1011JC | |
M16x1,5 | 10L | 432.1111JD | 432.1011JD | ||
M18x1,5 | 8S | 432.1111KD | 432.1011KD | ||
M16x1,5 | 10L | 432.1112JD | 432.1012JD | ||
M18x1,5 | 12L | 432.1112JE | 432.1012JE | ||
10 | M22x1,5 | 15L | 432.1112JG | 432.1012JG | 500Bar |
M20x1,5 | 12S | 432.1112KF | 432.1012KF | ||
M22x1,5 | 14S | 432.1112KG | 432.1012KG | ||
M22x1,5 | 15L | 432.1113JG | 432.1013JG | ||
13 | M26x1,5 | 18L | 432.1113JI | 432.1013JI | |
M24x1,5 | 16S | 432.1113KH | 432.1013KH | ||
M30x2 | 20S | 432.1113KJ | 432.1013KJ | ||
20 | M30x2 | 22L | 432.1114JJ | 432.1014JJ | |
M30x2 | 20S | 432.1114KJ | 432.1014KJ | 400Bar | |
M36x2 | 25S | 432.1114KK | 432.1014KK | ||
25 | M36x2 | 28L | 432.1115JK | 432.1015JK | 350Bar |
M42x2 | 30S | 432.1115KL | 432.1015KL | ||
DN | D / F | 有安装孔 | 无安装孔 | |
06 | ¼” BSP | 432.1111AB | 432.1011AB | 500Bar |
10 | ⅜” BSP | 432.1111AC | 432.1011AC | |
13 | ½” BSP | 432.1112AD | 432.1012AD | |
20 | ¾” BSP | 432.1113AE | 432.1013AE | 400Bar |
25 | 1” BSP | 432.1113AF | 432.1013AF | 350Bar |
1 ¼” BSP | 432.1114AG | 432.1014AG | ||
1 ½” BSP | 432.1115AH | 432.1015AH | ||
DN | D | 订货号 | |
¼” BSP | 452.1011AB | ||
¼” NPTF | 452.1011BB | ||
06 | 7/16” -12ORB | 452.1011GA | |
M12x1,5 6L | 452.1011JB | ||
M14x1,5 8L | 452.1011JC | ||
M16x1,5 10L | 452.1011JD | ||
M16x1,5 8S | 452.1011KD | ||
⅜” BSP | 452.1012AC | ||
⅜” NPTF | 452.1012BC | ||
9/16” -18ORB | 452.1012GC | 500Bar | |
10 | M16x1,5 10L | 452.1012JD | |
M18x1,5 12L | 452.1012JE | ||
M22x1,5 15L | 452.1012JG | ||
M20x1,5 12S | 452.1012KF | ||
M22x1,5 14S | 452.1012KG | ||
½” BSP | 452.1013AD | ||
½” NPTF | 452.1013BD | ||
13 | ¾” -16ORB | 452.1013GF | |
M22x1,5 15L | 452.1013JG | ||
M26x1,5 18L | 452.1013JI | ||
M24x1,5 16S | 452.1013KH | ||
M30x2 20S | 452.1013KJ | ||
¾” BSP | 452.1014AE | ||
¾” NPTF | 452.1014BE | ||
20 | 1 1/16”-12ORB | 452.1014GK | 400Bar |
M30x2 22L | 452.1014JJ | ||
M30x2 20S | 452.1014KJ | ||
M36x2 25S | 452.1014KK | ||
1” BSP | 452.1015AF | ||
25 | 1” NPTF | 452.1015BF | 350Bar |
1 2/16” -12ORB | 452.1015GO | ||
M36x2 28L | 452.1015JK |
DN | D | 订货号 | |
06 | ¼” BSP | 453.1011AB | 500Bar |
10 | ⅜” BSP | 453.1012AC | |
13 | ½” BSP | 453.1013AD | |
20 | ¾” BSP | 453.1014AE | 400Bar |
25 | 1” BSP | 453.1015AF | 350Bar |
阀体 外螺纹- 内螺纹
DN | ØA1 | ØA2 | 订货号 | CH1 | B | E | ||
06 | ¼” BSP M. | ¼” BSP | 502.19991AM | 19 | 50 | 12 | ||
10 | ⅜” BSP M. | ⅜” BSP | 502.19992AN | 22 | 59 | 13 | 350Bar | |
13 | ½” BSP M. | ½” BSP | 502.19993AO | 27 | 65 | 15 | ||
20 | ¾” BSP M. | ¾” BSP | 502.19993AP | 36 | 78 | 16 | ||
25 | 1” BSP M. | 1” BSP | 502.19993AQ | 41 | 92 | 18 |
阀体 内螺纹 – 内螺纹
DN | ØA1 | ØA2 | 订货号 | CH1 | B | ||
06 | ¼” BSP | ¼” BSP | 502.19991AB | 19 | 50 | ||
10 | ⅜” BSP | ⅜” BSP | 502.19992AC | 22 | 59 | 350Bar | |
13 | ½” BSP | ½” BSP | 502.19993AD | 27 | 65 | ||
20 | ¾” BSP | ¾” BSP | 502.19993AE | 36 | 78 | ||
25 | 1” BSP | 1” BSP | 502.19993AF | 41 | 92 |
阀芯
DN | ØA1 | 订货号 | ØG | L | ||
06 | ¼” BSP | 503.19991AM | 10 | 23 | ||
10 | ⅜” BSP | 503.19992AN | 13,80 | 23 | 350Bar | |
13 | ½” BSP | 503.19993AO | 16 | 34 | ||
20 | ¾” BSP | 503.19993AP | 20 | 34 | ||
25 | 1” BSP | 503.19993AQ | 24 | 43 |
ØA1/ ØA2 | 订货号 | |||||
⅛” BSP | 504.110000AA | |||||
⅛” NPTF | 504.110000BA | |||||
¼” BSP | 504.110001AB | |||||
¼” NPTF | 504.110001BB | |||||
⅜” BSP | 504.110002AC | |||||
⅜” NPTF | 504.110002BC | |||||
½” BSP | 504.110003AD | |||||
½” NPTF | 504.110003BD | 300Bar | ||||
¾” BSP | 504.110004AE | |||||
¾” NPTF | 504.110004BE | |||||
1” BSP | 504.110005AF | |||||
1” NPTF | 504.110005BF | |||||
1 ¼” BSP | 504.110006AG | |||||
1 ¼” NPTF | 504.110006BG | |||||
1 ½” BSP | 504.110007AH | |||||
1 ½” NPTF | 504.110007BH | |||||
2” BSP | 504.110008AI | 200Bar | ||||
2” NPTF | 504.110008BI | |||||
ØA1/ ØA2 | 订货号 | |||
⅛” BSP | 504.210000AA | |||
⅛” NPTF | 504.210000BA | |||
¼” BSP | 504.210001AB | |||
¼” NPTF | 504.210001BB | |||
⅜” BSP | 504.210002AC | |||
⅜” NPTF | 504.210002BC | |||
½” BSP | 504.210003AD | |||
½” NPTF | 504.210003BD | 300Bar | ||
¾” BSP | 504.210004AE | |||
¾” NPTF | 504.210004BE | |||
1” BSP | 504.210005AF | |||
1” NPTF | 504.210005BF | |||
1 ¼” BSP | 504.210006AG | |||
1 ¼” NPTF | 504.210006BG | |||
1 ½” BSP | 504.210007AH | |||
1 ½” NPTF | 504.210007BH | |||
2” BSP | 504.210008AI | 200Bar | ||
2” NPTF | 504.210008BI | |||
DN | ØA1 | ØA2 | 订货号 | |
04 | ⅛” BSP M. | ⅛” BSP | 505.110000AL | |
06 | ¼” BSP M. | ¼” BSP | 505.110001AM | |
10 | ⅜” BSP M. | ⅜” BSP | 505.110002AN | |
13 | ½” BSP M. | ½” BSP | 505.110003AO | 300Bar |
20 | ¾” BSP M. | ¾” BSP | 505.110004AP | |
25 | 1” BSP M. | 1” BSP | 505.110005AQ | |
32 | 1 ¼” BSP M. | 1 ¼” BSP | 505.110006AR | |
40 | 1 ½” BSP M. | 1 ½” BSP | 505.110007AS | |
50 | 2” BSP M. | 2” BSP | 505.110008AT 200Bar | |
|
